Archived Photos

(click on thumbnail photos to enlarge in bottom window)

October 30, 2006

test pile photo
test pile in ground photo
The 80' long test pile is being lifted into position to be driven into the ground.
The 80' long test pile is completely driven into
the ground.
concrete pile photo
temporary retaining wall photo
Concrete pile is being
loaded onto the barge.
Installation of coated permanent sheeting (black) adjacent to the temporary sheeting (brown) at the barge access area at Garrets Island.
.
